Knoxville Driveline – 1-Piece Aluminum Driveshaft for Mustang EcoBoost (6r80/10r80) (Rzeppa CV joint)

Knoxville Driveline – Mustang EcoBoost Driveshaft (10r80/6r80) (Rzeppa CV joint)

A direct upgrade over the factory two-piece steel driveshaft, this 1-piece aluminum driveshaft eliminates a known drivetrain weak point on the EcoBoost Mustang. Replacing the factory rubber Guibo disc with a High Speed Rzeppa CV joint, it delivers a stronger, more direct connection with no adapter required — it bolts directly in place of the factory rubber disc.

Switching to aluminum significantly reduces rotating mass, improving acceleration, throttle response, and cornering agility. Despite the weight savings, the design offers greater torsional rigidity than the factory steel unit, reducing driveline vibration and improving power transfer to the wheels. Installation is straightforward, though emergency brake cable bracket clearance or relocation may be necessary.

Installing a Rear Subframe Lock Out before installing this driveshaft is required. Failure to reinforce the rear cradle properly may result in driveline damage and will void the warranty.

Features:

• 3.5″ x .125″ aluminum construction
• High Speed Rzeppa (CV) joint
• No adapter needed — bolts directly in place of the factory Guibo (rubber disc)
• Significant weight reduction over factory 2-piece steel driveshaft
• Improved torsional rigidity reduces driveline vibration

Important Installation Notice:
Rear Subframe Lock Out must be installed prior to fitting this driveshaft. Damage resulting from an unreinforced rear cradle is not covered under warranty.

Applications:

• 2015-2017 Mustang EcoBoost — 6R80 transmission
• 2018-2023 Mustang EcoBoost — 10R80 transmission
• 2024+ Mustang EcoBoost — 10R80 transmission

Available at Engineered Motorsport Solutions INC — our team can help confirm fitment and walk you through the Rear Subframe Lock Out requirement before installation.
